错误 #4102

Uu上行灌包，基站侧RLC的LOG有“Received a unExpected pdu with sn”的错误打印

由 王 艳芳 在 大约 23 小时 之前添加. 更新于 大约 7 小时 之前.

状态:
进行中
优先级:
普通
指派给:
王 艳芳
开始日期:
2025-09-15
计划完成日期:
% 完成:

50%

预期时间:
40.00 小时
耗时:
50.00 小时

描述

梁娜在Uu业务测试过程发现，使用终端支持Uu预调度功能的协议栈版本后，全0数据的问题不再复现，但基站侧RLC的LOG有“Received a unExpected pdu with sn”的错误打印，出现的频率大概为几万包出现几次

历史记录

#1

由 王 艳芳 更新于 大约 23 小时 之前

  • 状态 从 新建 变更为 进行中
  • % 完成 从 0 变更为 50

通过昨日与今日梁娜提供的LOG数据分析后，结论如下：
1）从今日的基站侧LOG分析的结果，和昨天一致，发生“a unExpected pdu with sn”问题的MAC PDU为重复接收的MAC PDU，即基站在不同的预调度时机，解析到两包数据完全相同的TB，且使用的HARQ ID相同。
2）终端侧LOG分析，从终端发送数据里，可以找到基站解析的MAC TB数据，且HARQ ID一致，但终端侧MAC只组包且发送了一次，MAC并未在基站第二次解析到相同MAC TB的预调度时机收到使用该HARQ ID预调度的上行授权（UL GRANT）消息，所以，基站第二次解析到相同MAC TB的预调度时机，终端MAC并未组包发送数据。了解得知，RU目前没有清空已发送的HARQ数据，所以，推断为该数据为该HARQ存储的历史数据，被终端发送，因而，基站会解析到HARQ ID相同的重复MAC TB数据，其中包含了重复的RLC分段信息，导致了RLC的“a unExpected pdu with sn”错误；
3）引申的问题是，终端的L2为什么有时不能收到基站使用同一个HARQ ID的预调度的上行授权消息（UL GRANT)，和小葛讨论后，结论可能是终端侧对携带UL DCI信息的PDCCH的漏检问题。

#2

由 王 艳芳 更新于 大约 23 小时 之前

LOG分析的数据信息：
基站侧的MSG3信息，帮助同步基站和终端的时间信息
[18/09/2025 10:43:42.708][DBG_07]rgSCHRamCreateRaUe: RGSCH_RA_MSG3_PENDING add_to_raCbLst ue[0x7f6ad14d8020] ueid0
[18/09/2025 10:43:42.708][DBG_07]NR_RACH_DBG: k0 0 RA-RSP SCH Time 292:10
[18/09/2025 10:43:42.708][DBG_07]rgSCHLvl1GetCellMsg3K2, msg3Time[292:19] k2Idx4 k29 msg3TimeDelta3 minMsg3SchTime9
[18/09/2025 10:43:42.708][DBG_07]rgSCHCmnMsg3GrntReq: cellId(1) puschRsrcIdx(0) minRBReq(4) maxRBReq(4) sfn(292) slot(4)
[18/09/2025 10:43:42.708][DBG_07] PUSCH-MSG3: Alloctr response for CellId=1 UE=0 startRB=18 numRB=4 raType=1 TBSize:63 UlIdx:19 RIV:[837]
[18/09/2025 10:43:42.708][DBG_07]UeId17102 CellId1 HashList is Empty, gUe is not exist
[18/09/2025 10:43:42.708][DBG_07]cmnCreateGUeCb, gUeCb is created with ueIdx85 ueCb[0x7f6a8ca7c820] Crnti [17102] taskCb[0x7f6a8074f924]
终端侧的MSG3信息，帮助同步基站和终端的时间信息
[2025-09-18 11:15:38.860481[DEBUG]| src/ueapp/test/wn5gNrPsL1cSocket.c+3073 | wnSendUlSchToL1c | msg3 send!!!!!

基站第一次a unExpected pdu with sn ---harqId5
[18/09/2025 10:44:16.854][DBG_07]rgSCHLvl1TomCrcInd: rnti17102 harqId5 numLyrs1 iMcs16 rbStart4 rbNum265 tbSize11272 crcFail0 ucAckNack1 txCntr1 rv0 pusch[642 18] pdcch[642 6]
[18/09/2025 10:44:16.854][ERR_07]rgDUXDemuxData: ueId17102 pduLen11272
[18/09/2025 10:44:16.854][ERR_07]rgDUXDemuxData: pduPayload:[44]/[2]/[13]/[86]/[25]/[3]/[25]/[33]/[34]/[35]
[18/09/2025 10:44:16.854][ERR_07]rgDUXDemuxData: ueId17102 pduLen10738
[18/09/2025 10:44:16.854][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[80]/[28]/[d9]/[89]/[45]/[0]
[18/09/2025 10:44:16.854][ERR_07]rgDUXDemuxData: ueId17102 pduLen9402
[18/09/2025 10:44:16.854][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[80]/[28]/[da]/[89]/[45]/[0]
[18/09/2025 10:44:16.854][ERR_07]rgDUXDemuxData: ueId17102 pduLen8066
[18/09/2025 10:44:16.854][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[80]/[28]/[db]/[89]/[45]/[0]
[18/09/2025 10:44:16.854][ERR_07]rgDUXDemuxData: ueId17102 pduLen6730
[18/09/2025 10:44:16.854][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[80]/[28]/[dc]/[89]/[45]/[0]
[18/09/2025 10:44:16.854][ERR_07]rgDUXDemuxData: ueId17102 pduLen5394
[18/09/2025 10:44:16.854][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[80]/[28]/[dd]/[89]/[45]/[0]
[18/09/2025 10:44:16.854][ERR_07]rgDUXDemuxData: ueId17102 pduLen4058
[18/09/2025 10:44:16.854][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[80]/[28]/[de]/[89]/[45]/[0]
[18/09/2025 10:44:16.854][ERR_07]rgDUXDemuxData: ueId17102 pduLen2722
[18/09/2025 10:44:16.854][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[80]/[28]/[df]/[89]/[45]/[0]
[18/09/2025 10:44:16.854][ERR_07]rgDUXDemuxData: ueId17102 pduLen1386
[18/09/2025 10:44:16.854][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[80]/[28]/[e0]/[89]/[45]/[0]
[18/09/2025 10:44:16.854][ERR_07]rgDUXDemuxData: ueId17102 pduLen50
[18/09/2025 10:44:16.854][ERR_07]rgDUXDemuxData: pduPayload:[3d]/[55]/[3f]/[31]/[32]/[33]/[34]/[35]/[36]/[37]
[18/09/2025 10:44:16.854][ERR_07]rgDUXDemuxData: pduPayload:[3d]/[55]/[3f]/[31]/[32]/[33]/[34]/[35]/[36]/[37]
[18/09/2025 10:44:16.854][DBG_07]DEBUG: UE17102 Decoded Short BSR, Bsr21
[18/09/2025 10:44:16.854][ERR_07]rgDUXDemuxData: ueId17102 pduLen48
[18/09/2025 10:44:16.854][ERR_07]rgDUXDemuxData: pduPayload:[3f]/[31]/[32]/[33]/[34]/[35]/[36]/[37]/[38]/[39]

[18/09/2025 10:44:16.879][DBG_07]rgSCHLvl1TomCrcInd: rnti17102 harqId5 numLyrs1 iMcs16 rbStart4 rbNum35 tbSize1473 crcFail1 ucAckNack0 txCntr1 rv0 pusch[645 8] pdcch[644 16]

[18/09/2025 10:44:16.899][DBG_07]rgSCHLvl1TomCrcInd: rnti17102 harqId5 numLyrs1 iMcs16 rbStart4 rbNum265 tbSize11272 crcFail0 ucAckNack1 txCntr1 rv0 pusch[647 8] pdcch[646 16]
[18/09/2025 10:44:16.899][ERR_07]rgDUXDemuxData: ueId17102 pduLen11272
[18/09/2025 10:44:16.899][ERR_07]rgDUXDemuxData: pduPayload:[44]/[2]/[13]/[86]/[25]/[3]/[25]/[33]/[34]/[35]
[18/09/2025 10:44:16.899][ERR_07]rgDUXDemuxData: ueId17102 pduLen10738
[18/09/2025 10:44:16.899][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[80]/[28]/[d9]/[89]/[45]/[0]
[18/09/2025 10:44:16.899][ERR_07]rgDUXDemuxData: ueId17102 pduLen9402
[18/09/2025 10:44:16.899][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[80]/[28]/[da]/[89]/[45]/[0]
[18/09/2025 10:44:16.899][ERR_07]rgDUXDemuxData: ueId17102 pduLen8066
[18/09/2025 10:44:16.899][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[80]/[28]/[db]/[89]/[45]/[0]
[18/09/2025 10:44:16.899][ERR_07]rgDUXDemuxData: ueId17102 pduLen6730
[18/09/2025 10:44:16.899][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[80]/[28]/[dc]/[89]/[45]/[0]
[18/09/2025 10:44:16.899][ERR_07]rgDUXDemuxData: ueId17102 pduLen5394
[18/09/2025 10:44:16.899][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[80]/[28]/[dd]/[89]/[45]/[0]
[18/09/2025 10:44:16.899][ERR_07]rgDUXDemuxData: ueId17102 pduLen4058
[18/09/2025 10:44:16.899][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[80]/[28]/[de]/[89]/[45]/[0]
[18/09/2025 10:44:16.899][ERR_07]rgDUXDemuxData: ueId17102 pduLen2722
[18/09/2025 10:44:16.899][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[80]/[28]/[df]/[89]/[45]/[0]
[18/09/2025 10:44:16.899][ERR_07]rgDUXDemuxData: ueId17102 pduLen1386
[18/09/2025 10:44:16.899][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[80]/[28]/[e0]/[89]/[45]/[0]
[18/09/2025 10:44:16.899][ERR_07]rgDUXDemuxData: ueId17102 pduLen50
[18/09/2025 10:44:16.899][ERR_07]rgDUXDemuxData: pduPayload:[3d]/[55]/[3f]/[31]/[32]/[33]/[34]/[35]/[36]/[37]
[18/09/2025 10:44:16.899][DBG_07]DEBUG: UE17102 Decoded Short BSR, Bsr21
[18/09/2025 10:44:16.899][ERR_07]rgDUXDemuxData: ueId17102 pduLen48
[18/09/2025 10:44:16.899][ERR_07]rgDUXDemuxData: pduPayload:[3f]/[31]/[32]/[33]/[34]/[35]/[36]/[37]/[38]/[39]
[18/09/2025 10:44:16.899][DBG_07]RgLiTfuDatInd: other; UEid17102 SFN-Slot[647 8] dataSize11195 ceInfo.bitMask128 sduCnt9
[18/09/2025 10:44:16.899][DBG_26]Received a unExpected pdu with sn 1573 rbId:1 UEID:17102 CELLID:1

终端：
wnMacHasUlGrant | DU begin pro UL GRANT: tbSize11272 harqId5
[2025-09-18 11:16:13.077969[DEBUG]| src/ueapp/test/wn5gNrPsL1cSocket.c+3099 | wnSendUlSchToL1c |
ulTbReq->harqId:5,ulTbReq->rntiType:0,ulTbReq->bufferId:11272,ulTbReq->tbSize:68,ulTbReq->payload:[2]/[13]/[86]/[25]/[3]/[25]/[33]/[34]/[35]/[8effaec0]

[2025-09-18 11:16:13.117707[INFO ]| src/l2/mac/csrc/wn5gNrUePsMacSlotSync.c+398 | wnMacHasUlGrant | DU begin pro UL GRANT: tbSize1537 harqId6
[2025-09-18 11:16:13.117885[DEBUG]| src/ueapp/test/wn5gNrPsL1cSocket.c+3099 | wnSendUlSchToL1c |
ulTbReq->harqId:6,ulTbReq->rntiType:0,ulTbReq->bufferId:1537,ulTbReq->tbSize:68,ulTbReq->payload:[4]/[ab]/[86]/[29]/[0]/[8d]/[39]/[30]/[31]/[8effaec0]

[2025-09-18 11:16:13.127696[INFO ]| src/l2/mac/csrc/wn5gNrUePsMacSlotSync.c+398 | wnMacHasUlGrant | DU begin pro UL GRANT: tbSize11272 harqId2

[2025-09-18 11:16:13.262883[DEBUG]| src/ueapp/test/wn5gNrPsL1cSocket.c+3099 | wnSendUlSchToL1c |
ulTbReq->harqId:5,ulTbReq->rntiType:0,ulTbReq->bufferId:2817,ulTbReq->tbSize:68,ulTbReq->payload:[5]/[35]/[0]/[80]/[29]/[93]/[89]/[45]/[0]/[8effaec0]

第二次 a unExpected pdu with sn ----------harqId6
基站：
[18/09/2025 10:44:24.341][DBG_07]rgSCHLvl1TomCrcInd: rnti17102 harqId6 numLyrs1 iMcs16 rbStart4 rbNum250 tbSize10497 crcFail0 ucAckNack1 txCntr1 rv0 pusch[369 8] pdcch[368 16]
[18/09/2025 10:44:24.341][ERR_07]rgDUXDemuxData: ueId17102 pduLen10497
[18/09/2025 10:44:24.341][ERR_07]rgDUXDemuxData: pduPayload:[44]/[3]/[50]/[8a]/[67]/[1]/[e8]/[36]/[37]/[38]
[18/09/2025 10:44:24.341][ERR_07]rgDUXDemuxData: ueId17102 pduLen9646
[18/09/2025 10:44:24.341][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[80]/[45]/[c]/[89]/[45]/[0]
[18/09/2025 10:44:24.341][ERR_07]rgDUXDemuxData: ueId17102 pduLen8310
[18/09/2025 10:44:24.341][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[80]/[45]/[d]/[89]/[45]/[0]
[18/09/2025 10:44:24.341][ERR_07]rgDUXDemuxData: ueId17102 pduLen6974
[18/09/2025 10:44:24.341][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[80]/[45]/[e]/[89]/[45]/[0]
[18/09/2025 10:44:24.341][ERR_07]rgDUXDemuxData: ueId17102 pduLen5638
[18/09/2025 10:44:24.341][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[80]/[45]/[f]/[89]/[45]/[0]
[18/09/2025 10:44:24.341][ERR_07]rgDUXDemuxData: ueId17102 pduLen4302
[18/09/2025 10:44:24.341][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[80]/[45]/[10]/[89]/[45]/[0]
[18/09/2025 10:44:24.341][ERR_07]rgDUXDemuxData: ueId17102 pduLen2966
[18/09/2025 10:44:24.341][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[80]/[45]/[11]/[89]/[45]/[0]
[18/09/2025 10:44:24.341][ERR_07]rgDUXDemuxData: ueId17102 pduLen1630
[18/09/2025 10:44:24.341][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[80]/[45]/[12]/[89]/[45]/[0]
[18/09/2025 10:44:24.341][ERR_07]rgDUXDemuxData: ueId17102 pduLen294
[18/09/2025 10:44:24.341][ERR_07]rgDUXDemuxData: pduPayload:[44]/[1]/[1d]/[4a]/[68]/[80]/[45]/[13]/[89]/[45]
[18/09/2025 10:44:24.341][ERR_07]rgDUXDemuxData: ueId17102 pduLen6
[18/09/2025 10:44:24.341][ERR_07]rgDUXDemuxData: pduPayload:[3d]/[56]/[3f]/[35]/[36]/[37]/[0]/[0]/[0]/[0]
[18/09/2025 10:44:24.341][DBG_07]DEBUG: UE17102 Decoded Short BSR, Bsr22
[18/09/2025 10:44:24.341][ERR_07]rgDUXDemuxData: ueId17102 pduLen4
[18/09/2025 10:44:24.341][ERR_07]rgDUXDemuxData: pduPayload:[3f]/[35]/[36]/[37]/[0]/[0]/[0]/[0]/[0]/[0]

[18/09/2025 10:44:24.390][DBG_07]rgSCHLvl1TomCrcInd: rnti17102 harqId6 numLyrs1 iMcs16 rbStart4 rbNum265 tbSize11272 crcFail1 ucAckNack0 txCntr1 rv0 pusch[374 8] pdcch[373 16]

[18/09/2025 10:44:24.415][DBG_07]rgSCHLvl1TomCrcInd: rnti17102 harqId6 numLyrs1 iMcs16 rbStart4 rbNum250 tbSize10497 crcFail0 ucAckNack1 txCntr1 rv0 pusch[376 18] pdcch[376 6]
[18/09/2025 10:44:24.415][ERR_07]rgDUXDemuxData: ueId17102 pduLen10497
[18/09/2025 10:44:24.415][ERR_07]rgDUXDemuxData: pduPayload:[44]/[3]/[50]/[8a]/[67]/[1]/[e8]/[36]/[37]/[38]
[18/09/2025 10:44:24.415][ERR_07]rgDUXDemuxData: ueId17102 pduLen9646
[18/09/2025 10:44:24.415][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[80]/[45]/[c]/[89]/[45]/[0]
[18/09/2025 10:44:24.415][ERR_07]rgDUXDemuxData: ueId17102 pduLen8310
[18/09/2025 10:44:24.415][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[80]/[45]/[d]/[89]/[45]/[0]
[18/09/2025 10:44:24.415][ERR_07]rgDUXDemuxData: ueId17102 pduLen6974
[18/09/2025 10:44:24.415][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[80]/[45]/[e]/[89]/[45]/[0]
[18/09/2025 10:44:24.415][ERR_07]rgDUXDemuxData: ueId17102 pduLen5638
[18/09/2025 10:44:24.415][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[80]/[45]/[f]/[89]/[45]/[0]
[18/09/2025 10:44:24.415][ERR_07]rgDUXDemuxData: ueId17102 pduLen4302
[18/09/2025 10:44:24.415][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[80]/[45]/[10]/[89]/[45]/[0]
[18/09/2025 10:44:24.415][ERR_07]rgDUXDemuxData: ueId17102 pduLen2966
[18/09/2025 10:44:24.415][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[80]/[45]/[11]/[89]/[45]/[0]
[18/09/2025 10:44:24.415][ERR_07]rgDUXDemuxData: ueId17102 pduLen1630
[18/09/2025 10:44:24.415][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[80]/[45]/[12]/[89]/[45]/[0]
[18/09/2025 10:44:24.415][ERR_07]rgDUXDemuxData: ueId17102 pduLen294
[18/09/2025 10:44:24.415][ERR_07]rgDUXDemuxData: pduPayload:[44]/[1]/[1d]/[4a]/[68]/[80]/[45]/[13]/[89]/[45]
[18/09/2025 10:44:24.415][ERR_07]rgDUXDemuxData: ueId17102 pduLen6
[18/09/2025 10:44:24.415][ERR_07]rgDUXDemuxData: pduPayload:[3d]/[56]/[3f]/[35]/[36]/[37]/[0]/[0]/[0]/[0]
[18/09/2025 10:44:24.415][DBG_07]DEBUG: UE17102 Decoded Short BSR, Bsr22
[18/09/2025 10:44:24.415][ERR_07]rgDUXDemuxData: ueId17102 pduLen4
[18/09/2025 10:44:24.415][ERR_07]rgDUXDemuxData: pduPayload:[3f]/[35]/[36]/[37]/[0]/[0]/[0]/[0]/[0]/[0]
[18/09/2025 10:44:24.415][DBG_07]RgLiTfuDatInd: other; UEid17102 SFN-Slot[376 18] dataSize10464 ceInfo.bitMask128 sduCnt9
[18/09/2025 10:44:24.415][DBG_26]Received a unExpected pdu with sn 2663 rbId:1 UEID:17102 CELLID:1
[18/09/2025 10:44:24.415][DBG_26]Received a unExpected pdu with sn 2664 rbId:1 UEID:17102 CELLID:1

终端
[2025-09-18 11:16:20.582959[DEBUG]| src/ueapp/test/wn5gNrPsL1cSocket.c+3099 | wnSendUlSchToL1c |
ulTbReq->harqId:6,ulTbReq->rntiType:0,ulTbReq->bufferId:10497,ulTbReq->tbSize:68,ulTbReq->payload:[3]/[50]/[8a]/[67]/[1]/[e8]/[36]/[37]/[38]/[8effaec0]

[2025-09-18 11:16:20.707964[DEBUG]| src/ueapp/test/wn5gNrPsL1cSocket.c+3099 | wnSendUlSchToL1c |
ulTbReq->harqId:6,ulTbReq->rntiType:0,ulTbReq->bufferId:11272,ulTbReq->tbSize:68,ulTbReq->payload:[3]/[60]/[8a]/[7a]/[1]/[d8]/[30]/[31]/[32]/[8effaec0]

第三次a unExpected pdu with sn --------harqId9
[18/09/2025 10:44:44.412][DBG_07]rgSCHLvl1TomCrcInd: rnti17102 harqId9 numLyrs1 iMcs16 rbStart4 rbNum265 tbSize11272 crcFail0 ucAckNack1 txCntr1 rv0 pusch[333 8] pdcch[332 16]
[18/09/2025 10:44:44.412][ERR_07]rgDUXDemuxData: ueId17102 pduLen11272
[18/09/2025 10:44:44.412][ERR_07]rgDUXDemuxData: pduPayload:[44]/[3]/[f3]/[85]/[e7]/[1]/[45]/[33]/[34]/[35]
[18/09/2025 10:44:44.412][ERR_07]rgDUXDemuxData: ueId17102 pduLen10258
[18/09/2025 10:44:44.412][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[80]/[90]/[a9]/[89]/[45]/[0]
[18/09/2025 10:44:44.412][ERR_07]rgDUXDemuxData: ueId17102 pduLen8922
[18/09/2025 10:44:44.412][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[80]/[90]/[aa]/[89]/[45]/[0]
[18/09/2025 10:44:44.412][ERR_07]rgDUXDemuxData: ueId17102 pduLen7586
[18/09/2025 10:44:44.412][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[80]/[90]/[ab]/[89]/[45]/[0]
[18/09/2025 10:44:44.412][ERR_07]rgDUXDemuxData: ueId17102 pduLen6250
[18/09/2025 10:44:44.412][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[80]/[90]/[ac]/[89]/[45]/[0]
[18/09/2025 10:44:44.412][ERR_07]rgDUXDemuxData: ueId17102 pduLen4914
[18/09/2025 10:44:44.412][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[80]/[90]/[ad]/[89]/[45]/[0]
[18/09/2025 10:44:44.412][ERR_07]rgDUXDemuxData: ueId17102 pduLen3578
[18/09/2025 10:44:44.412][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[80]/[90]/[ae]/[89]/[45]/[0]
[18/09/2025 10:44:44.412][ERR_07]rgDUXDemuxData: ueId17102 pduLen2242
[18/09/2025 10:44:44.412][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[80]/[90]/[af]/[89]/[45]/[0]
[18/09/2025 10:44:44.412][ERR_07]rgDUXDemuxData: ueId17102 pduLen906
[18/09/2025 10:44:44.412][ERR_07]rgDUXDemuxData: pduPayload:[44]/[3]/[59]/[45]/[e8]/[80]/[90]/[b0]/[89]/[45]
[18/09/2025 10:44:44.412][ERR_07]rgDUXDemuxData: ueId17102 pduLen46
[18/09/2025 10:44:44.412][ERR_07]rgDUXDemuxData: pduPayload:[3d]/[56]/[3f]/[38]/[39]/[30]/[31]/[32]/[33]/[34]
[18/09/2025 10:44:44.412][DBG_07]DEBUG: UE17102 Decoded Short BSR, Bsr22
[18/09/2025 10:44:44.412][ERR_07]rgDUXDemuxData: ueId17102 pduLen44
[18/09/2025 10:44:44.412][ERR_07]rgDUXDemuxData: pduPayload:[3f]/[38]/[39]/[30]/[31]/[32]/[33]/[34]/[35]/[36]

[18/09/2025 10:44:44.437][DBG_07]rgSCHLvl1TomCrcInd: rnti17102 harqId9 numLyrs1 iMcs16 rbStart4 rbNum93 tbSize3969 crcFail1 ucAckNack0 txCntr1 rv0 pusch[335 18] pdcch[335 6]

[18/09/2025 10:44:44.457][DBG_07]rgSCHLvl1TomCrcInd: rnti17102 harqId9 numLyrs1 iMcs16 rbStart4 rbNum265 tbSize11272 crcFail0 ucAckNack1 txCntr1 rv0 pusch[337 18] pdcch[337 6]
[18/09/2025 10:44:44.457][ERR_07]rgDUXDemuxData: ueId17102 pduLen11272
[18/09/2025 10:44:44.457][ERR_07]rgDUXDemuxData: pduPayload:[44]/[3]/[f3]/[85]/[e7]/[1]/[45]/[33]/[34]/[35]
[18/09/2025 10:44:44.457][ERR_07]rgDUXDemuxData: ueId17102 pduLen10258
[18/09/2025 10:44:44.457][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[80]/[90]/[a9]/[89]/[45]/[0]
[18/09/2025 10:44:44.457][ERR_07]rgDUXDemuxData: ueId17102 pduLen8922
[18/09/2025 10:44:44.457][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[80]/[90]/[aa]/[89]/[45]/[0]
[18/09/2025 10:44:44.457][ERR_07]rgDUXDemuxData: ueId17102 pduLen7586
[18/09/2025 10:44:44.457][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[80]/[90]/[ab]/[89]/[45]/[0]
[18/09/2025 10:44:44.457][ERR_07]rgDUXDemuxData: ueId17102 pduLen6250
[18/09/2025 10:44:44.457][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[80]/[90]/[ac]/[89]/[45]/[0]
[18/09/2025 10:44:44.457][ERR_07]rgDUXDemuxData: ueId17102 pduLen4914
[18/09/2025 10:44:44.457][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[80]/[90]/[ad]/[89]/[45]/[0]
[18/09/2025 10:44:44.457][ERR_07]rgDUXDemuxData: ueId17102 pduLen3578
[18/09/2025 10:44:44.457][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[80]/[90]/[ae]/[89]/[45]/[0]
[18/09/2025 10:44:44.457][ERR_07]rgDUXDemuxData: ueId17102 pduLen2242
[18/09/2025 10:44:44.457][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[80]/[90]/[af]/[89]/[45]/[0]
[18/09/2025 10:44:44.457][ERR_07]rgDUXDemuxData: ueId17102 pduLen906
[18/09/2025 10:44:44.457][ERR_07]rgDUXDemuxData: pduPayload:[44]/[3]/[59]/[45]/[e8]/[80]/[90]/[b0]/[89]/[45]
[18/09/2025 10:44:44.457][ERR_07]rgDUXDemuxData: ueId17102 pduLen46
[18/09/2025 10:44:44.457][ERR_07]rgDUXDemuxData: pduPayload:[3d]/[56]/[3f]/[38]/[39]/[30]/[31]/[32]/[33]/[34]
[18/09/2025 10:44:44.457][DBG_07]DEBUG: UE17102 Decoded Short BSR, Bsr22
[18/09/2025 10:44:44.457][ERR_07]rgDUXDemuxData: ueId17102 pduLen44
[18/09/2025 10:44:44.457][ERR_07]rgDUXDemuxData: pduPayload:[3f]/[38]/[39]/[30]/[31]/[32]/[33]/[34]/[35]/[36]
[18/09/2025 10:44:44.457][DBG_07]RgLiTfuDatInd: other; UEid17102 SFN-Slot[337 18] dataSize11199 ceInfo.bitMask128 sduCnt9
[18/09/2025 10:44:44.457][DBG_26]Received a unExpected pdu with sn 1511 rbId:1 UEID:17102 CELLID:1
[18/09/2025 10:44:44.457][DBG_26]Received a unExpected pdu with sn 1512 rbId:1 UEID:17102 CELLID:1

终端：
[2025-09-18 11:16:40.702824[DEBUG]| src/ueapp/test/wn5gNrPsL1cSocket.c+3099 | wnSendUlSchToL1c |
ulTbReq->harqId:9,ulTbReq->rntiType:0,ulTbReq->bufferId:11272,ulTbReq->tbSize:68,ulTbReq->payload:[3]/[f3]/[85]/[e7]/[1]/[45]/[33]/[34]/[35]/[8effaec0]

[2025-09-18 11:16:40.972682[DEBUG]| src/ueapp/test/wn5gNrPsL1cSocket.c+3099 | wnSendUlSchToL1c |
ulTbReq->harqId:9,ulTbReq->rntiType:0,ulTbReq->bufferId:3969,ulTbReq->tbSize:68,ulTbReq->payload:[5]/[35]/[0]/[80]/[91]/[b6]/[89]/[45]/[0]/[8effaec0]

第四次 a unExpected pdu with sn 2840 harqId1

[18/09/2025 10:45:20.405][DBG_07]rgSCHLvl1TomCrcInd: rnti17102 harqId1 numLyrs1 iMcs16 rbStart4 rbNum250 tbSize10497 crcFail0 ucAckNack1 txCntr1 rv0 pusch[869 8] pdcch[868 16]
[18/09/2025 10:45:20.405][ERR_07]rgDUXDemuxData: ueId17102 pduLen10497
[18/09/2025 10:45:20.405][ERR_07]rgDUXDemuxData: pduPayload:[44]/[1]/[af]/[8b]/[17]/[3]/[89]/[33]/[34]/[35]
[18/09/2025 10:45:20.405][ERR_07]rgDUXDemuxData: ueId17102 pduLen10063
[18/09/2025 10:45:20.405][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[81]/[18]/[45]/[89]/[45]/[0]
[18/09/2025 10:45:20.405][ERR_07]rgDUXDemuxData: ueId17102 pduLen8727
[18/09/2025 10:45:20.405][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[81]/[18]/[46]/[89]/[45]/[0]
[18/09/2025 10:45:20.405][ERR_07]rgDUXDemuxData: ueId17102 pduLen7391
[18/09/2025 10:45:20.405][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[81]/[18]/[47]/[89]/[45]/[0]
[18/09/2025 10:45:20.405][ERR_07]rgDUXDemuxData: ueId17102 pduLen6055
[18/09/2025 10:45:20.405][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[81]/[18]/[48]/[89]/[45]/[0]
[18/09/2025 10:45:20.405][ERR_07]rgDUXDemuxData: ueId17102 pduLen4719
[18/09/2025 10:45:20.405][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[81]/[18]/[49]/[89]/[45]/[0]
[18/09/2025 10:45:20.405][ERR_07]rgDUXDemuxData: ueId17102 pduLen3383
[18/09/2025 10:45:20.405][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[81]/[18]/[4a]/[89]/[45]/[0]
[18/09/2025 10:45:20.405][ERR_07]rgDUXDemuxData: ueId17102 pduLen2047
[18/09/2025 10:45:20.405][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[81]/[18]/[4b]/[89]/[45]/[0]
[18/09/2025 10:45:20.405][ERR_07]rgDUXDemuxData: ueId17102 pduLen711
[18/09/2025 10:45:20.405][ERR_07]rgDUXDemuxData: pduPayload:[44]/[2]/[67]/[4b]/[18]/[81]/[18]/[4c]/[89]/[45]
[18/09/2025 10:45:20.405][ERR_07]rgDUXDemuxData: ueId17102 pduLen93
[18/09/2025 10:45:20.405][ERR_07]rgDUXDemuxData: pduPayload:[3d]/[53]/[3f]/[30]/[31]/[32]/[33]/[34]/[35]/[36]
[18/09/2025 10:45:20.405][DBG_07]DEBUG: UE17102 Decoded Short BSR, Bsr19
[18/09/2025 10:45:20.405][ERR_07]rgDUXDemuxData: ueId17102 pduLen91
[18/09/2025 10:45:20.405][ERR_07]rgDUXDemuxData: pduPayload:[3f]/[30]/[31]/[32]/[33]/[34]/[35]/[36]/[37]/[38]

[18/09/2025 10:45:20.454][DBG_07]rgSCHLvl1TomCrcInd: rnti17102 harqId1 numLyrs1 iMcs16 rbStart4 rbNum82 tbSize3457 crcFail1 ucAckNack0 txCntr1 rv0 pusch[874 8] pdcch[873 16]

[18/09/2025 10:45:20.474][DBG_07]rgSCHLvl1TomCrcInd: rnti17102 harqId1 numLyrs1 iMcs16 rbStart4 rbNum250 tbSize10497 crcFail0 ucAckNack1 txCntr1 rv0 pusch[876 8] pdcch[875 16]
[18/09/2025 10:45:20.474][ERR_07]rgDUXDemuxData: ueId17102 pduLen10497
[18/09/2025 10:45:20.474][ERR_07]rgDUXDemuxData: pduPayload:[44]/[1]/[af]/[8b]/[17]/[3]/[89]/[33]/[34]/[35]
[18/09/2025 10:45:20.474][ERR_07]rgDUXDemuxData: ueId17102 pduLen10063
[18/09/2025 10:45:20.474][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[81]/[18]/[45]/[89]/[45]/[0]
[18/09/2025 10:45:20.474][ERR_07]rgDUXDemuxData: ueId17102 pduLen8727
[18/09/2025 10:45:20.474][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[81]/[18]/[46]/[89]/[45]/[0]
[18/09/2025 10:45:20.474][ERR_07]rgDUXDemuxData: ueId17102 pduLen7391
[18/09/2025 10:45:20.474][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[81]/[18]/[47]/[89]/[45]/[0]
[18/09/2025 10:45:20.474][ERR_07]rgDUXDemuxData: ueId17102 pduLen6055
[18/09/2025 10:45:20.474][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[81]/[18]/[48]/[89]/[45]/[0]
[18/09/2025 10:45:20.474][ERR_07]rgDUXDemuxData: ueId17102 pduLen4719
[18/09/2025 10:45:20.474][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[81]/[18]/[49]/[89]/[45]/[0]
[18/09/2025 10:45:20.474][ERR_07]rgDUXDemuxData: ueId17102 pduLen3383
[18/09/2025 10:45:20.474][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[81]/[18]/[4a]/[89]/[45]/[0]
[18/09/2025 10:45:20.474][ERR_07]rgDUXDemuxData: ueId17102 pduLen2047
[18/09/2025 10:45:20.474][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[81]/[18]/[4b]/[89]/[45]/[0]
[18/09/2025 10:45:20.474][ERR_07]rgDUXDemuxData: ueId17102 pduLen711
[18/09/2025 10:45:20.474][ERR_07]rgDUXDemuxData: pduPayload:[44]/[2]/[67]/[4b]/[18]/[81]/[18]/[4c]/[89]/[45]
[18/09/2025 10:45:20.474][ERR_07]rgDUXDemuxData: ueId17102 pduLen93
[18/09/2025 10:45:20.474][ERR_07]rgDUXDemuxData: pduPayload:[3d]/[53]/[3f]/[30]/[31]/[32]/[33]/[34]/[35]/[36]
[18/09/2025 10:45:20.474][DBG_07]DEBUG: UE17102 Decoded Short BSR, Bsr19
[18/09/2025 10:45:20.474][ERR_07]rgDUXDemuxData: ueId17102 pduLen91
[18/09/2025 10:45:20.474][ERR_07]rgDUXDemuxData: pduPayload:[3f]/[30]/[31]/[32]/[33]/[34]/[35]/[36]/[37]/[38]
[18/09/2025 10:45:20.474][DBG_07]RgLiTfuDatInd: other; UEid17102 SFN-Slot[876 8] dataSize10377 ceInfo.bitMask128 sduCnt9
[18/09/2025 10:45:20.474][DBG_26]Received a unExpected pdu with sn 2839 rbId:1 UEID:17102 CELLID:1
[18/09/2025 10:45:20.474][DBG_26]Received a unExpected pdu with sn 2840 rbId:1 UEID:17102 CELLID:1

终端：
[2025-09-18 11:17:16.782565[DEBUG]| src/ueapp/test/wn5gNrPsL1cSocket.c+3099 | wnSendUlSchToL1c |
ulTbReq->harqId:1,ulTbReq->rntiType:0,ulTbReq->bufferId:10497,ulTbReq->tbSize:68,ulTbReq->payload:[1]/[af]/[8b]/[17]/[3]/[89]/[33]/[34]/[35]/[8effaec0]

[2025-09-18 11:17:16.877637[DEBUG]| src/ueapp/test/wn5gNrPsL1cSocket.c+3099 | wnSendUlSchToL1c |
ulTbReq->harqId:1,ulTbReq->rntiType:0,ulTbReq->bufferId:11272,ulTbReq->tbSize:68,ulTbReq->payload:[3]/[23]/[8b]/[25]/[2]/[15]/[31]/[32]/[33]/[8effaec0]

第五次 a unExpected pdu with sn 2527 harqId2

[18/09/2025 10:45:45.284][DBG_07]rgSCHLvl1TomCrcInd: rnti17102 harqId2 numLyrs1 iMcs16 rbStart4 rbNum250 tbSize10497 crcFail0 ucAckNack1 txCntr1 rv0 pusch[291 8] pdcch[290 16]
[18/09/2025 10:45:45.284][ERR_07]rgDUXDemuxData: ueId17102 pduLen10497
[18/09/2025 10:45:45.284][ERR_07]rgDUXDemuxData: pduPayload:[44]/[4]/[6c]/[89]/[df]/[0]/[cc]/[32]/[33]/[34]
[18/09/2025 10:45:45.284][ERR_07]rgDUXDemuxData: ueId17102 pduLen9362
[18/09/2025 10:45:45.284][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[81]/[75]/[f5]/[89]/[45]/[0]
[18/09/2025 10:45:45.284][ERR_07]rgDUXDemuxData: ueId17102 pduLen8026
[18/09/2025 10:45:45.284][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[81]/[75]/[f6]/[89]/[45]/[0]
[18/09/2025 10:45:45.284][ERR_07]rgDUXDemuxData: ueId17102 pduLen6690
[18/09/2025 10:45:45.284][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[81]/[75]/[f7]/[89]/[45]/[0]
[18/09/2025 10:45:45.284][ERR_07]rgDUXDemuxData: ueId17102 pduLen5354
[18/09/2025 10:45:45.284][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[81]/[75]/[f8]/[89]/[45]/[0]
[18/09/2025 10:45:45.284][ERR_07]rgDUXDemuxData: ueId17102 pduLen4018
[18/09/2025 10:45:45.284][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[81]/[75]/[f9]/[89]/[45]/[0]
[18/09/2025 10:45:45.284][ERR_07]rgDUXDemuxData: ueId17102 pduLen2682
[18/09/2025 10:45:45.284][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[81]/[75]/[fa]/[89]/[45]/[0]
[18/09/2025 10:45:45.284][ERR_07]rgDUXDemuxData: ueId17102 pduLen1346
[18/09/2025 10:45:45.284][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[81]/[75]/[fb]/[89]/[45]/[0]
[18/09/2025 10:45:45.284][ERR_07]rgDUXDemuxData: ueId17102 pduLen10
[18/09/2025 10:45:45.284][ERR_07]rgDUXDemuxData: pduPayload:[3d]/[58]/[3f]/[32]/[33]/[34]/[35]/[36]/[37]/[38]
[18/09/2025 10:45:45.284][DBG_07]DEBUG: UE17102 Decoded Short BSR, Bsr24
[18/09/2025 10:45:45.284][ERR_07]rgDUXDemuxData: ueId17102 pduLen8
[18/09/2025 10:45:45.284][ERR_07]rgDUXDemuxData: pduPayload:[3f]/[32]/[33]/[34]/[35]/[36]/[37]/[38]/[0]/[0]
[18/0

[18/09/2025 10:45:45.534][DBG_07]rgSCHLvl1TomCrcInd: rnti17102 harqId2 numLyrs1 iMcs16 rbStart4 rbNum179 tbSize7557 crcFail1 ucAckNack0 txCntr1 rv0 pusch[316 8] pdcch[315 16]

[18/09/2025 10:45:45.554][DBG_07]rgSCHLvl1TomCrcInd: rnti17102 harqId2 numLyrs1 iMcs16 rbStart4 rbNum250 tbSize10497 crcFail0 ucAckNack1 txCntr1 rv0 pusch[318 8] pdcch[317 16]
[18/09/2025 10:45:45.554][ERR_07]rgDUXDemuxData: ueId17102 pduLen10497
[18/09/2025 10:45:45.554][ERR_07]rgDUXDemuxData: pduPayload:[44]/[4]/[6c]/[89]/[df]/[0]/[cc]/[32]/[33]/[34]
[18/09/2025 10:45:45.554][ERR_07]rgDUXDemuxData: ueId17102 pduLen9362
[18/09/2025 10:45:45.554][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[81]/[75]/[f5]/[89]/[45]/[0]
[18/09/2025 10:45:45.554][ERR_07]rgDUXDemuxData: ueId17102 pduLen8026
[18/09/2025 10:45:45.554][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[81]/[75]/[f6]/[89]/[45]/[0]
[18/09/2025 10:45:45.554][ERR_07]rgDUXDemuxData: ueId17102 pduLen6690
[18/09/2025 10:45:45.554][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[81]/[75]/[f7]/[89]/[45]/[0]
[18/09/2025 10:45:45.554][ERR_07]rgDUXDemuxData: ueId17102 pduLen5354
[18/09/2025 10:45:45.554][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[81]/[75]/[f8]/[89]/[45]/[0]
[18/09/2025 10:45:45.554][ERR_07]rgDUXDemuxData: ueId17102 pduLen4018
[18/09/2025 10:45:45.554][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[81]/[75]/[f9]/[89]/[45]/[0]
[18/09/2025 10:45:45.554][ERR_07]rgDUXDemuxData: ueId17102 pduLen2682
[18/09/2025 10:45:45.554][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[81]/[75]/[fa]/[89]/[45]/[0]
[18/09/2025 10:45:45.554][ERR_07]rgDUXDemuxData: ueId17102 pduLen1346
[18/09/2025 10:45:45.554][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[81]/[75]/[fb]/[89]/[45]/[0]
[18/09/2025 10:45:45.554][ERR_07]rgDUXDemuxData: ueId17102 pduLen10
[18/09/2025 10:45:45.554][ERR_07]rgDUXDemuxData: pduPayload:[3d]/[58]/[3f]/[32]/[33]/[34]/[35]/[36]/[37]/[38]
[18/09/2025 10:45:45.554][DBG_07]DEBUG: UE17102 Decoded Short BSR, Bsr24
[18/09/2025 10:45:45.554][ERR_07]rgDUXDemuxData: ueId17102 pduLen8
[18/09/2025 10:45:45.554][ERR_07]rgDUXDemuxData: pduPayload:[3f]/[32]/[33]/[34]/[35]/[36]/[37]/[38]/[0]/[0]
[18/09/2025 10:45:45.554][DBG_07]RgLiTfuDatInd: other; UEid17102 SFN-Slot[318 8] dataSize10463 ceInfo.bitMask128 sduCnt8
[18/09/2025 10:45:45.554][DBG_26]Received a unExpected pdu with sn 2527 rbId:1 UEID:17102 CELLID:1

终端：
[2025-09-18 11:17:41.722323[DEBUG]| src/ueapp/test/wn5gNrPsL1cSocket.c+3099 | wnSendUlSchToL1c |
ulTbReq->harqId:2,ulTbReq->rntiType:0,ulTbReq->bufferId:10497,ulTbReq->tbSize:68,ulTbReq->payload:[4]/[6c]/[89]/[df]/[0]/[cc]/[32]/[33]/[34]/[8effaec0]

[2025-09-18 11:17:42.202325[DEBUG]| src/ueapp/test/wn5gNrPsL1cSocket.c+3099 | wnSendUlSchToL1c |
ulTbReq->harqId:2,ulTbReq->rntiType:0,ulTbReq->bufferId:11272,ulTbReq->tbSize:4,ulTbReq->payload:[6d]/[8a]/[28]/[4]/[cb]/[35]/[36]/[37]/[38]/[8effaec0]

第六次
[18/09/2025 10:45:47.813][DBG_07]rgSCHLvl1TomCrcInd: rnti17102 harqId1 numLyrs1 iMcs16 rbStart4 rbNum265 tbSize11272 crcFail0 ucAckNack1 txCntr1 rv0 pusch[544 18] pdcch[544 6]
[18/09/2025 10:45:47.813][ERR_07]rgDUXDemuxData: ueId17102 pduLen11272
[18/09/2025 10:45:47.813][ERR_07]rgDUXDemuxData: pduPayload:[44]/[4]/[f4]/[8b]/[5f]/[0]/[44]/[36]/[37]/[38]
[18/09/2025 10:45:47.813][ERR_07]rgDUXDemuxData: ueId17102 pduLen10001
[18/09/2025 10:45:47.813][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[81]/[7f]/[82]/[89]/[45]/[0]
[18/09/2025 10:45:47.813][ERR_07]rgDUXDemuxData: ueId17102 pduLen8665
[18/09/2025 10:45:47.813][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[81]/[7f]/[83]/[89]/[45]/[0]
[18/09/2025 10:45:47.813][ERR_07]rgDUXDemuxData: ueId17102 pduLen7329
[18/09/2025 10:45:47.813][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[81]/[7f]/[84]/[89]/[45]/[0]
[18/09/2025 10:45:47.813][ERR_07]rgDUXDemuxData: ueId17102 pduLen5993
[18/09/2025 10:45:47.813][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[81]/[7f]/[85]/[89]/[45]/[0]
[18/09/2025 10:45:47.813][ERR_07]rgDUXDemuxData: ueId17102 pduLen4657
[18/09/2025 10:45:47.813][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[81]/[7f]/[86]/[89]/[45]/[0]
[18/09/2025 10:45:47.813][ERR_07]rgDUXDemuxData: ueId17102 pduLen3321
[18/09/2025 10:45:47.813][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[81]/[7f]/[87]/[89]/[45]/[0]
[18/09/2025 10:45:47.813][ERR_07]rgDUXDemuxData: ueId17102 pduLen1985
[18/09/2025 10:45:47.813][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[81]/[7f]/[88]/[89]/[45]/[0]
[18/09/2025 10:45:47.813][ERR_07]rgDUXDemuxData: ueId17102 pduLen649
[18/09/2025 10:45:47.813][ERR_07]rgDUXDemuxData: pduPayload:[44]/[2]/[80]/[4b]/[60]/[81]/[7f]/[89]/[89]/[45]
[18/09/2025 10:45:47.813][ERR_07]rgDUXDemuxData: ueId17102 pduLen6
[18/09/2025 10:45:47.813][ERR_07]rgDUXDemuxData: pduPayload:[3d]/[55]/[3f]/[3d]/[57]/[3f]/[0]/[0]/[0]/[0]
[18/09/2025 10:45:47.813][DBG_07]DEBUG: UE17102 Decoded Short BSR, Bsr21
[18/09/2025 10:45:47.813][ERR_07]rgDUXDemuxData: ueId17102 pduLen4
[18/09/2025 10:45:47.813][ERR_07]rgDUXDemuxData: pduPayload:[3f]/[3d]/[57]/[3f]/[0]/[0]/[0]/[0]/[0]/[0]

[18/09/2025 10:45:47.858][DBG_07]rgSCHLvl1TomCrcInd: rnti17102 harqId1 numLyrs1 iMcs16 rbStart4 rbNum265 tbSize11272 crcFail0 ucAckNack1 txCntr1 rv0 pusch[549 8] pdcch[548 16]
[18/09/2025 10:45:47.858][ERR_07]rgDUXDemuxData: ueId17102 pduLen11272
[18/09/2025 10:45:47.858][ERR_07]rgDUXDemuxData: pduPayload:[44]/[4]/[f4]/[8b]/[5f]/[0]/[44]/[36]/[37]/[38]
[18/09/2025 10:45:47.858][ERR_07]rgDUXDemuxData: ueId17102 pduLen10001
[18/09/2025 10:45:47.858][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[81]/[7f]/[82]/[89]/[45]/[0]
[18/09/2025 10:45:47.858][ERR_07]rgDUXDemuxData: ueId17102 pduLen8665
[18/09/2025 10:45:47.858][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[81]/[7f]/[83]/[89]/[45]/[0]
[18/09/2025 10:45:47.858][ERR_07]rgDUXDemuxData: ueId17102 pduLen7329
[18/09/2025 10:45:47.858][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[81]/[7f]/[84]/[89]/[45]/[0]
[18/09/2025 10:45:47.858][ERR_07]rgDUXDemuxData: ueId17102 pduLen5993
[18/09/2025 10:45:47.858][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[81]/[7f]/[85]/[89]/[45]/[0]
[18/09/2025 10:45:47.858][ERR_07]rgDUXDemuxData: ueId17102 pduLen4657
[18/09/2025 10:45:47.858][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[81]/[7f]/[86]/[89]/[45]/[0]
[18/09/2025 10:45:47.858][ERR_07]rgDUXDemuxData: ueId17102 pduLen3321
[18/09/2025 10:45:47.858][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[81]/[7f]/[87]/[89]/[45]/[0]
[18/09/2025 10:45:47.858][ERR_07]rgDUXDemuxData: ueId17102 pduLen1985
[18/09/2025 10:45:47.858][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[81]/[7f]/[88]/[89]/[45]/[0]
[18/09/2025 10:45:47.858][ERR_07]rgDUXDemuxData: ueId17102 pduLen649
[18/09/2025 10:45:47.858][ERR_07]rgDUXDemuxData: pduPayload:[44]/[2]/[80]/[4b]/[60]/[81]/[7f]/[89]/[89]/[45]
[18/09/2025 10:45:47.858][ERR_07]rgDUXDemuxData: ueId17102 pduLen6
[18/09/2025 10:45:47.858][ERR_07]rgDUXDemuxData: pduPayload:[3d]/[55]/[3f]/[3d]/[57]/[3f]/[0]/[0]/[0]/[0]
[18/09/2025 10:45:47.858][DBG_07]DEBUG: UE17102 Decoded Short BSR, Bsr21
[18/09/2025 10:45:47.858][ERR_07]rgDUXDemuxData: ueId17102 pduLen4
[18/09/2025 10:45:47.858][ERR_07]rgDUXDemuxData: pduPayload:[3f]/[3d]/[57]/[3f]/[0]/[0]/[0]/[0]/[0]/[0]
[18/09/2025 10:45:47.858][DBG_07]RgLiTfuDatInd: other; UEid17102 SFN-Slot[549 8] dataSize11239 ceInfo.bitMask128 sduCnt9
[18/09/2025 10:45:47.858][DBG_26]Received a unExpected pdu with sn 2911 rbId:1 UEID:17102 CELLID:1
[18/09/2025 10:45:47.858][DBG_26]Received a unExpected pdu with sn 2912 rbId:1 UEID:17102 CELLID:1

终端
[2025-09-18 11:17:44.257363[DEBUG]| src/ueapp/test/wn5gNrPsL1cSocket.c+3099 | wnSendUlSchToL1c |
ulTbReq->harqId:1,ulTbReq->rntiType:0,ulTbReq->bufferId:11272,ulTbReq->tbSize:68,ulTbReq->payload:[4]/[f4]/[8b]/[5f]/[0]/[44]/[36]/[37]/[38]/[8effaec0]

[2025-09-18 11:17:44.392225[DEBUG]| src/ueapp/test/wn5gNrPsL1cSocket.c+3099 | wnSendUlSchToL1c |
ulTbReq->harqId:1,ulTbReq->rntiType:0,ulTbReq->bufferId:7557,ulTbReq->tbSize:68,ulTbReq->payload:[5]/[35]/[0]/[81]/[80]/[b]/[89]/[45]/[0]/[8effaec0]

第七次
[18/09/2025 10:45:59.225][DBG_07]rgSCHLvl1TomCrcInd: rnti17102 harqId4 numLyrs1 iMcs16 rbStart4 rbNum265 tbSize11272 crcFail0 ucAckNack1 txCntr1 rv0 pusch[664 18] pdcch[664 6]
[18/09/2025 10:45:59.225][ERR_07]rgDUXDemuxData: ueId17102 pduLen11272
[18/09/2025 10:45:59.225][ERR_07]rgDUXDemuxData: pduPayload:[44]/[1]/[2f]/[82]/[40]/[4]/[9]/[31]/[32]/[33]
[18/09/2025 10:45:59.225][ERR_07]rgDUXDemuxData: ueId17102 pduLen10966
[18/09/2025 10:45:59.225][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[81]/[aa]/[85]/[89]/[45]/[0]
[18/09/2025 10:45:59.225][ERR_07]rgDUXDemuxData: ueId17102 pduLen9630
[18/09/2025 10:45:59.225][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[81]/[aa]/[86]/[89]/[45]/[0]
[18/09/2025 10:45:59.225][ERR_07]rgDUXDemuxData: ueId17102 pduLen8294
[18/09/2025 10:45:59.225][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[81]/[aa]/[87]/[89]/[45]/[0]
[18/09/2025 10:45:59.225][ERR_07]rgDUXDemuxData: ueId17102 pduLen6958
[18/09/2025 10:45:59.225][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[81]/[aa]/[88]/[89]/[45]/[0]
[18/09/2025 10:45:59.225][ERR_07]rgDUXDemuxData: ueId17102 pduLen5622
[18/09/2025 10:45:59.225][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[81]/[aa]/[89]/[89]/[45]/[0]
[18/09/2025 10:45:59.225][ERR_07]rgDUXDemuxData: ueId17102 pduLen4286
[18/09/2025 10:45:59.225][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[81]/[aa]/[8a]/[89]/[45]/[0]
[18/09/2025 10:45:59.225][ERR_07]rgDUXDemuxData: ueId17102 pduLen2950
[18/09/2025 10:45:59.225][ERR_07]rgDUXDemuxData: pduPayload:[3d]/[50]/[3f]/[33]/[34]/[35]/[36]/[37]/[38]/[39]
[18/09/2025 10:45:59.225][DBG_07]DEBUG: UE17102 Decoded Short BSR, Bsr16
[18/09/2025 10:45:59.225][ERR_07]rgDUXDemuxData: ueId17102 pduLen2948
[18/09/2025 10:45:59.225][ERR_07]rgDUXDemuxData: pduPayload:[3f]/[33]/[34]/[35]/[36]/[37]/[38]/[39]/[30]/[31]

[18/09/2025 10:45:59.280][DBG_07]rgSCHLvl1TomCrcInd: rnti17102 harqId4 numLyrs1 iMcs16 rbStart4 rbNum48 tbSize2049 crcFail1 ucAckNack0 txCntr1 rv0 pusch[670 8] pdcch[669 16]

[18/09/2025 10:45:59.300][DBG_07]rgSCHLvl1TomCrcInd: rnti17102 harqId4 numLyrs1 iMcs16 rbStart4 rbNum265 tbSize11272 crcFail0 ucAckNack1 txCntr1 rv0 pusch[672 8] pdcch[671 16]
[18/09/2025 10:45:59.300][ERR_07]rgDUXDemuxData: ueId17102 pduLen11272
[18/09/2025 10:45:59.300][ERR_07]rgDUXDemuxData: pduPayload:[44]/[1]/[2f]/[82]/[40]/[4]/[9]/[31]/[32]/[33]
[18/09/2025 10:45:59.300][ERR_07]rgDUXDemuxData: ueId17102 pduLen10966
[18/09/2025 10:45:59.300][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[81]/[aa]/[85]/[89]/[45]/[0]
[18/09/2025 10:45:59.300][ERR_07]rgDUXDemuxData: ueId17102 pduLen9630
[18/09/2025 10:45:59.300][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[81]/[aa]/[86]/[89]/[45]/[0]
[18/09/2025 10:45:59.300][ERR_07]rgDUXDemuxData: ueId17102 pduLen8294
[18/09/2025 10:45:59.300][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[81]/[aa]/[87]/[89]/[45]/[0]
[18/09/2025 10:45:59.300][ERR_07]rgDUXDemuxData: ueId17102 pduLen6958
[18/09/2025 10:45:59.300][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[81]/[aa]/[88]/[89]/[45]/[0]
[18/09/2025 10:45:59.300][ERR_07]rgDUXDemuxData: ueId17102 pduLen5622
[18/09/2025 10:45:59.300][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[81]/[aa]/[89]/[89]/[45]/[0]
[18/09/2025 10:45:59.300][ERR_07]rgDUXDemuxData: ueId17102 pduLen4286
[18/09/2025 10:45:59.300][ERR_07]rgDUXDemuxData: pduPayload:[44]/[5]/[35]/[0]/[81]/[aa]/[8a]/[89]/[45]/[0]
[18/09/2025 10:45:59.300][ERR_07]rgDUXDemuxData: ueId17102 pduLen2950
[18/09/2025 10:45:59.300][ERR_07]rgDUXDemuxData: pduPayload:[3d]/[50]/[3f]/[33]/[34]/[35]/[36]/[37]/[38]/[39]
[18/09/2025 10:45:59.300][DBG_07]DEBUG: UE17102 Decoded Short BSR, Bsr16
[18/09/2025 10:45:59.300][ERR_07]rgDUXDemuxData: ueId17102 pduLen2948
[18/09/2025 10:45:59.300][ERR_07]rgDUXDemuxData: pduPayload:[3f]/[33]/[34]/[35]/[36]/[37]/[38]/[39]/[30]/[31]
[18/09/2025 10:45:59.300][DBG_07]RgLiTfuDatInd: other; UEid17102 SFN-Slot[672 8] dataSize8301 ceInfo.bitMask128 sduCnt7
[18/09/2025 10:45:59.300][DBG_26]Received a unExpected pdu with sn 576 rbId:1 UEID:17102 CELLID:1

终端：
[2025-09-18 11:17:55.697213[DEBUG]| src/ueapp/test/wn5gNrPsL1cSocket.c+3099 | wnSendUlSchToL1c |
ulTbReq->harqId:4,ulTbReq->rntiType:0,ulTbReq->bufferId:11272,ulTbReq->tbSize:68,ulTbReq->payload:[1]/[2f]/[82]/[40]/[4]/[9]/[31]/[32]/[33]/[8effaec0]

[2025-09-18 11:17:55.797270[DEBUG]| src/ueapp/test/wn5gNrPsL1cSocket.c+3099 | wnSendUlSchToL1c |
ulTbReq->harqId:4,ulTbReq->rntiType:0,ulTbReq->bufferId:11272,ulTbReq->tbSize:68,ulTbReq->payload:[2]/[79]/[82]/[4e]/[2]/[bf]/[31]/[32]/[33]/[8effaec0]

#3

由 王 艳芳 更新于 大约 7 小时 之前

待物理层完成HARQ BUFFER清0后复测该问题是否存在。

导出 Atom PDF
